4D深水井泵
Suspended Deep Well Pump
| PUMP TYPE 泵浦型式 4D | STAGES 段數 | MOTOR 馬力 | Q=Capacity 水量 | PUMP Dimension 泵浦尺寸 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 /min | 5 | 10 | 15 | 20 | 25 | 30 | 35 | 37 | ||||||
| m3/h | 0.3 | 0.6 | 0.9 | 1.2 | 1.5 | 1.8 | 2.1 | 2.22 | Lenght(mm) 長度 | WEIGHT(Kg) 重量 | ||||
| KW | HP | H=Total Head in Meters 揚程 | ||||||||||||
| ST 05-10 | 10 | 0.37 | 0.5 | 62 | 52 | 41 | 30 | 18 | 12 | 5 | 0 | 388 | 3.43 | |
| ST 05-15 | 15 | 0.55 | 0.75 | 104 | 91 | 78 | 60 | 40 | 22 | 13 | 0 | 500 | 4.40 | |
| ST 05-20 | 20 | 0.75 | 1.0 | 128 | 111 | 94 | 70 | 44 | 23 | 13 | 0 | 612 | 5.36 | |
| ST 05-30 | 30 | 1.1 | 1.5 | 190 | 163 | 137 | 100 | 59 | 30 | 13 | 0 | 871 | 7.54 | |
| ST 05-40 | 40 | 1.5 | 2.0 | 252 | 216 | 173 | 127 | 80 | 40 | 15 | 0 | 1095 | 9.47 | |
